Abstract
Design and analysis of piezoelectric actuators having over 20% effective strain using an exponential strain amplification mechanism are presented in this paper. Piezoelectric ceramic material, such as lead zirconate titanate (PZT), has large stress and bandwidth, but its extremely small strain, i.e., only 0.1%, has been a major bottleneck for broad applications. This paper presents a new strain amplification design, called a "nested rhombus" multilayer mechanism, that increases strain exponentially through its hierarchical cellular structure. This allows for over 20% effective strain. In order to design the whole actuator structure, not only the compliance of piezoelectric material but also the compliance of the amplification structures needs to be taken into account. This paper addresses how the output force and displacement are attenuated by the compliance involved in the strain amplification mechanism through kinematic and static analysis. An insightful lumped parameter model is proposed to quantify the performance degradation and facilitate design tradeoffs. A prototype-nested PZT cellular actuator that weighs only 15 g has produced 21% effective strain (2.5 mm displacement from 12-mm actuator length and 30 mm width) and 1.7 N blocking force.
