Abstract
Energy harvesting from cardiac motion is an attractive means to avoid the use of batteries in implantable sensors and pacemakers. A single implantable device would ideally integrate both sensing and self-powering functionality.
This work describes a novel electromagnetic system that achieves high sensitivity detection of the heart rate while simultaneously providing adaptive energy harvesting capability using a tunable resonance cantilever mechanism.
Our prototype design exhibits tunability of resonant frequency across the range of physiologic heart rates at a combination of lengths and angular orientations. Our initial prototype also produces between 3.0 [Formula: see text]W and 20.6 [Formula: see text]W of power at heart rates of 79-243 bpm, respectively.
The prototype device can harvest sufficient energy to sustain implantable cardiac devices such as a leadless pacemaker. The system in this paper has the potential to eliminate batteries in certain implantable cardiac devices and thereby improve overall patient monitoring and treatment.
