Abstract
A low voltage, low power, high sampling rate track-and-hold amplifier (THA) architecture is proposed. The THA samples at 20 GS/s and combines a distributed amplifier and a switched cascode stage. Power consumption for the circuit is 71 mW and it occupies 0.09 mm(2) in 0.13 mu m CMOS. The THA delivers up to 34 dB spur-free dynamic range (SFDR) and -32 dB total harmonic distortion (THD) at a supply voltage of 1.2 V. Input return loss remains below -10 dB over all frequencies of interest, while output return loss remains below -15 dB.
