Abstract
Researchers have evaluated the stiffness matrix for different robots and structures, including the Stewart platform style tensile truss. However, none of the configurations analyzed to date involve "dual-reeving," a common industrial rigging technique whereby cables are spatial loops, vs. open-loop elements, such as those represented by simple line segments. The 4-node/4-loop kinematic configuration analyzed contains 4 symmetric nodes and loops and provides competition for a comparable-sized Stewart platform from the perspective of directional stiffness. Additionally, like the Stewart platform, only a modest amount of off-diagonal compliance matrix elements are present, which from a practical and intuitive point of view, can be advantageous. The methodology used and illustrated in detail is easily generalized to adapt to more involved configurations. Numerical results are obtained for a specific example and compared with those from a Stewart platform. Lastly, some experimental results compare favorably with those derived analytically and evaluated numerically.
