Electromagnetic Transient Simulation of a Back-to-Back Voltage Source Converter Based Transmission Scheme

M.M. Zakaria Moustafa; S. Filizadeh; IEEE; Mohamed M. Moustafa

doi:10.1109/CCECE.2007.391

Back

Conference proceeding

Electromagnetic Transient Simulation of a Back-to-Back Voltage Source Converter Based Transmission Scheme

M.M. Zakaria Moustafa, S. Filizadeh, IEEE and Mohamed M. Moustafa

2007 Canadian Conference on Electrical and Computer Engineering, pp.1570-1573

04/2007

DOI: https://doi.org/10.1109/CCECE.2007.391

Abstract

Circuit simulation

Converters

Electromagnetic modeling

EMTDC

Filtering

Power conversion

Power harmonic filters

PSCAD

System performance

Voltage

This paper presents a detailed model of back-to-back VSC transmission scheme in an electromagnetic transient simulation program (PSCAD/EMTDC) in order to investigate system performance. This includes the simulation model of VSC and its interpolated firing, harmonic filtering and control circuits in PSCAD. Decoupled vector-control in a synchronously rotating reference frame for the VSC is implemented on both sending and receiving ends. The interconnections and interrelations between the various blocks have been specified in order to investigate a detailed design of a true working system.

Metrics

1 Record Views

Details

Title: Electromagnetic Transient Simulation of a Back-to-Back Voltage Source Converter Based Transmission Scheme
Author/Creator: M.M. Zakaria Moustafa - University of Manitoba
S. Filizadeh - University of Manitoba
IEEE
Mohamed M. Moustafa - Electrical & Computer Engineering
Publication Details: 2007 Canadian Conference on Electrical and Computer Engineering, pp.1570-1573
Publisher: IEEE
Academic Unit: Electrical & Computer Engineering; School of Engineering
Language: English
Resource Type: Conference proceeding
Record Identifier: 991015225099303691
