Abstract
Fused deposition modelling (FDM) creates three-dimensional parts by feeding a rigid thermoplastic filament through a heated barrel to achieve a semi-fluid state and then extruding it layer-by-layer to create a part geometry. The melt flow behavior within FDM must be analyzed in order to correctly understand the temperature gradients within the system to promote part quality, process control, and efficiency. The presented research consists of analyzing the melt flow behavior of polymer poly(lactic) acid (PLA) within FDM. This includes an experimental analysis of the power output of the resistive heat source, a theoretical analysis of external coefficients of heat transfer, and an experimental validation of liquefier temperatures. A three-dimensional fluid-flow model is created using the accurate geometry of the extruder assembly, calculated conditions from initial experimental results, and referenced material properties. Results of this research include a significant temperature difference between the areas of the liquefier assembly close in proximity to the power source to those further away such as the inlet and outlet, suggesting that external heat transfer mechanisms play a significant role in liquefier dynamics, contrary to the more common assumption of constant wall temperature or constant heat flux used in modeling. The research presented provides new information regarding the melt flow of PLA, a method of modeling external heat transfer, and a way of understanding power consumption that can lead to liquefier design improvements. The process itself will also aid in identifying modeling considerations for further investigations of melt flow involving various extruder designs and material options. Specifically, the use of this type of comprehensive model is of interest to the additive manufacturing community with respect to thermally sensitive component specification and heating and cooling needs within process based on changing system parameters such as extrusion temperature and mass flow rates (i.e. material feed rate and/or change in extrusion diameter).
